U-HRV 4800 Series​

U-ERV 4800 Standard Features Industry Standard Comparison
Airflow Range:0 to 6400 CFM [4800 Rated]Fully Variable ECM+ Remote Fan Modulation
Dimensions:54” L X 32” D X 12” Height [x2]2-4X Smaller Size
Ultra Lightweight:784 lbs [98 lbs per module]2.5X Lighter (Varies by Options)
AHRI 1060 Tested Core:EWT-11-42 [x8]Counterflow plate-type, heat and humidity transfer
 HWT-11-42 [x8]Counterflow plate-type, heat-only transfer or condensing wrap-around application
Sensible Efficiency:73% @ 4800 SCFMUp to 90% Possible
Latent Efficiency:63% @ 4800 SCFMUp to 70% Possible
Total Efficiency:69% @ 4800 SCFMUp to 80% Possible
Exhaust Air Transfer:ZeroGood for Bathroom Exhaust, Laboratories, Hospitals
Cost:Lowest InstalledLower transport, installation, maintenance and fan energy costs
Minimal Maintenance:Filters @ 3-6 monthsTotal qty. 40, MERV 8: 21”X 5.25“ X 2” (Actual Size)
Stack Multiple Modules:Vertical or HorizontalPatented design – a single duct will connect to multiple U-ERVs
Fan Motors:ECM+>1.0 CFM/Watt @ 4800 SCFM
 IP68 RatedVariable Airflow adjustability & balancing with mechanical turn potentiometers
  Remote Variable Airflow adjustability via 0-10V signal
Antimicrobial Membrane:Salt / CeramicProven highly antimicrobial without the addition of additives
Like a UV Light:MERV 11 EquivalenceActively kills bacteria flowing with both airstreams
Non-Fused Disconnect:Exterior Rated UL98Lowers Installed Cost – Defeatable Lockout For Safe Access
Application:Any OrientationUniversal Compatibility for Bolt-on, Roof-top, Exterior or Interior Installation
Electrical Power:Universal Input AC or DC90 to 264 VAC Input (50/60Hz) or 40 to 370 VDC Input
Extreme Exterior Shell:Carbon Infused PolypropyleneCorrosion Proof, double wall construction
  Nano-particle metal-oxide insulation

                                    External Static Pressure at 4800 SCFM         90 to 264 VAC Input (50/60 Hz)                40 to 350 VDC Input

  SupplyExhaustWeight120 VAC230 VAC208 VAC55.2 VDC255 VDC255 VDC
Model NumberType(in. w.g.)(in. w.g.)(lbs.)1Ø(Amps)1Ø(Amps)3Ø(Amps)(Amps)(Amps)(Amps)
UHRV 4800LLSensible0.50.578462.836.621.9129.628.020.4
UHRV 4800HHSensible2.02.0848108.655.733.3205.644.532.4
UHRV 4800LHSensible0.52.081675.040.428.2168.036.426.5
UHRV 4800HLSensible2.00.581675.040.428.2168.036.426.5
