U-ERV 4800 Series​


Specifications
Models
Dimensions
Specifications

U-ERV 4800 Standard Features   Industry Standard Comparison
Airflow Range: 0 to 6400 CFM [4800 Rated] Fully Variable ECM+ Remote Fan Modulation
Dimensions: 54” L X 32” D X 12” Height [x2] 2-4X Smaller Size
Ultra Lightweight: 784 lbs [98 lbs per module] 2.5X Lighter (Varies by Options)
AHRI 1060 Tested Core: EWT-11-42 [x8] Counterflow plate-type, heat and humidity transfer
  HWT-11-42 [x8] Counterflow plate-type, heat-only transfer or condensing wrap-around application
Sensible Efficiency: 73% @ 4800 SCFM Up to 90% Possible
Latent Efficiency: 63% @ 4800 SCFM Up to 70% Possible
Total Efficiency: 69% @ 4800 SCFM Up to 80% Possible
Exhaust Air Transfer: Zero Good for Bathroom Exhaust, Laboratories, Hospitals
Cost: Lowest Installed Lower transport, installation, maintenance and fan energy costs
Minimal Maintenance: Filters @ 3-6 months Total qty. 40, MERV 8: 21”X 5.25“ X 2” (Actual Size)
Stack Multiple Modules: Vertical or Horizontal Patented design – a single duct will connect to multiple U-ERVs
Fan Motors: ECM+ Variable Airflow adjustability & balancing with mechanical turn potentiometers
  IP68 Rated Remote Variable Airflow adjustability via 0-10V signal
Antimicrobial Membrane: Salt / Ceramic Proven highly antimicrobial without the addition of additives
Like a UV Light: MERV 11 Equivalence Actively kills bacteria flowing with both airstreams
Non-Fused Disconnect: Exterior Rated UL98 Lowers Installed Cost – Defeatable Lockout For Safe Access
Application: Any Orientation Universal Compatibility for Bolt-on, Roof-top, Exterior or Interior Installation
Electrical Power: Universal Input AC or DC 90 to 264 VAC Input (50/60Hz) or 40 to 370 VDC Input
Extreme Exterior Shell: Carbon Infused Polypropylene Corrosion Proof, double wall construction
    Nano-particle metal-oxide insulation

Models

                                    External Static Pressure at 4800 SCFM         90 to 264 VAC Input (50/60 Hz)                40 to 350 VDC Input

    Supply Exhaust Weight 120 VAC 230 VAC 208 VAC 55.2 VDC 255 VDC 255 VDC
Model Number Type (in. w.g.) (in. w.g.) (lbs.) 1Ø(Amps) 1Ø(Amps) 3Ø(Amps) (Amps) (Amps) (Amps)
UERV 4800LL Enthalpy 0.5 0.5 784 62.8 36.6 21.9 129.6 28.0 20.4
UERV 4800HH Enthalpy 2.0 2.0 848 108.6 55.7 33.3 205.6 44.5 32.4
UERV 4800LH Enthalpy 0.5 2.0 816 75.0 40.4 28.2 168.0 36.4 26.5
UERV 4800HL Enthalpy 2.0 0.5 816 75.0 40.4 28.2 168.0 36.4 26.5

Dimensions
